SPECIFICATION
Rated Power 3200VA
AC Input
Ac Input 230 VAC
Voltage 170~280 VAC (For Personal Computer)
Selectable Voltage Range 90~280VAC (For Home Appliances)
Frequency Range 50 HZ / 60 HZ (Auto Sensing)
AC OUTPUT
AC Voltage Regulation 230 VAC + 5%
Nominal Current Output 14.54A
Efficiency (Peak) PV to INV 97%
Efficiency (Peak) Battery to INV 94%
Transfer Time 10ms Typical(MS); 20ms Stapical( Appliances)
BATTERY AND AC CHARGER
Battery Voltage 24 VDC
Floating Charge Voltage 27 VDC
Overcharge Protection 33 VDC
Maximum AC Charge Current 80A
SOLAR CHARGER
Maximum PV Array Power 4500W
MPPT Range @ Operating Voltage 55-430 VDC
Maximum PV Array Open Circuit Voltage 430 VDC
Maximum Charge Current TRUE (MPPT) 80A
Maximum PV Input Current 18A
Maximum Efficiency 98%
PHYSICAL
Communication Interface RS323/GPRS/Wi-Fi
OPERATING ENVIRONMNET
Humidity 5% to 95% Relative Humidity (Non~Condensing)
Operating Temperature 0°C~55°C
Storage Temperature -15°C-~60°C
