Description
CPU Intel® Celeron® 2.0GHz quad-core processor (burst up to 2.42GHz)
DRAM TS-453 Pro-8G: 8GB DDR3L RAM (4GB x 2)
TS-453 Pro: 2GB DDR3L RAM
Total memory slots: 2 (expandable up to 8GB)
Flash Memory 512MB DOM
Hard Disk Drive 4 x 3.5”or 2.5”SATA 6Gb/s, SATA 3Gb/s hard drive or SSD
1. The system is shipped without HDD.
2. For the HDD compatibility list, please visit Compatibility list
Hard Disk Tray 4 x Hot-swappable tray
LAN Port 4 x Gigabit RJ-45 Ethernet port
LED Indicators Status, LAN, USB, HDD 1-4
USB
3 x USB 3.2 Gen 1 port (Front: 1, Rear: 2)
2 x USB 2.0 port (Rear: 2)
Support USB printer, pen drive, and USB UPS etc.
HDMI™ 1
Buttons Power/Status, USB One-Touch-Backup, reset
Alarm Buzzer System warning
IR Receiver MCE-compatible
Form Factor Tower
Dimensions 177 (H)x 180(W) x 235(D) mm
6.97(H) x 7.09(W) x 9.25(D) inch
Weight Net: 3.65 kg (8.04 lbs)
Gross: 4.65 kg (10.24lbs)
Power Consumption (W) HDD standby: 20.71 W
S3 sleep: 0.8W
In operation: 33.13W
(with 4 x 1TB HDD installed)
Sound Level* Sound pressure (LpAm) :20.3 dB(A)
Temperature 0-40˚C
Humidity 5~95% RH non-condensing, wet bulb: 27˚C
Power Supply ATX 250W, 100-240V
Secure Design Kensington security slot for theft prevention
Fan 1 x quiet cooling fan ( 9cm, 12V DC)
