Details
TypeHybrid Inverter
Kilowatt5-10 kW
BrandOthers
ConditionNew
Description
INVERTER CHARGER
MODEL NAME: RELAX-10.2KW
MODEL NUMBER:RELAX-10 2KW
Color: White and Black
Operating Temperature Range:-10-50°C
920122501060199
PV INPUT:
Nominal operating voltage: 360Vdc
Vmax PV: 500Vdc
PV input Voltage range: 90-450Vdc
Imax PV/Channels: 18.0A/2Channels
Full Load MPPT Range: 360-450Vdc
Maximum PV Input Power: 5400W+5400W
Maximum Solar Charging Current: 160A
GRID/AC OUTPUT:
Nominal Output Voltage: 220/230/240Vac
Feed-in Grid Voltage Range: 195-253Vac
Feed-in Grid Frequency Range: 50+1Hz
Nominal Output Current: 44.3A
Power Factor Range:>0.99
Maximum Conversion Efficiency(DC/AC):98%
Nominal Operating Frequency: 50/60Hz
TWO LOAD OUTPUT POWER
Full Load: 10200W
Maximum Main Load: 10200W
Maximum Second Load:3400W
Main Load Cut Off Voltage:52VDC
Main Load Return Voltage:54VDC
AC INPUT:
Nominal operating voltage: 230Vac
Maximum input current:50A
Nominal operating frequency: 50/60Hz
Surge power:20400VA
Maximum AC Charging Current: 140A
BATTERY
Battery voltage 48VDC
Maximum battery current:212.5A
MADE IN CHINA
